Rear Subframe - Genuine - Late Type

Name: Rear Subframe - Genuine - Late Type
SKU: KHB10024
Price: 464.172001 GBP
Availability: InStock

Be the first to review this product

Special Price £464.17 £386.81 Regular Price £504.01

In stock

SKU

KHB10024

Genuine Mini rear subframe for Minis from 1991 onwards.

Frequently Bought Together

Rear Subframe - Genuine - Late Type
Special Price £464.17 £386.81 Regular Price £504.01
Rear Valance Filler Saloon - LH
Special Price £15.13 £12.61 Regular Price £16.66
Rear Subframe Mounting Bush kit - Genuine
Special Price £61.21 £51.01 Regular Price £64.68
Radius Arm Outer Support Bracket - LH
Special Price £15.14 £12.62 Regular Price £17.50
Poly Bush Full Car Kit - 76-01
Special Price £40.56 £33.80 Regular Price £51.30

Details

KHB10024 genuine Mini rear subframe to suit models from 1991 onwards fitted with 12" wheels.

This rear subframe is manufactured by British Motor Heritage using the original tooling and jigs, ensuring that this is the best replacement part for your Mini if a new subframe is required.

For Minis fitted with 13" wheels and Sportspack models please look at KHB100590 subframe.

This subframe has the late type exhaust hanger rods as used on 1991 onwards Mini models.

For ease of fitment we recommend you use the Heritage HMP841014 subframe fitting kit, as this contains all the bolts and bushes needed for the job.

Buy genuine Mini subframes and Mini suspension parts from Mini Sport, the world's premier online Mini store!

Find all related parts with our Easy Parts Finder

No.

Description

Notes

Part No.

1	All (Hydrolastic) wet suspension models		21A2160	Qty
1	'59-'91 dry suspension models - no exhaust hangers		FAM6292	Qty
1	'92-'97 models with exhaust hangers		KHB10023	Qty
1	Sportspack '97-'01		KHB100590	Qty
1	Automatic Subframe assembly - '92-'97		KHB10024	Qty
1	KHB10024 including trunnions & bushes (as pic)		KHB10026	Out of stock
	Genuine - Mk4 built up and ready to fit		HMP241002	Qty
1	'59-'91 dry suspension models - no exhaust hangers		40-10-007	Out of stock
1	'59-'91 models - no exhaust hangers powder coated		40-10-007PC	Qty
1	'91-'97 dry suspension models - with exhaust hangers		40-10-008	Out of stock
1	'91-'97 models - exhaust hangers powder coated		40-10-008PC	Qty
1	All (Hydrolastic) wet suspension models)		40-10-006	Qty
2	RH radius arm/subframe bracket, each		21A195	Qty
3	LH radius arm/subframe bracket, each		21A197	Qty
7	Rear subframe fitting kit (as pic)		HMP841014	Qty
8	Rear trunnion pin, each		21A1440	Qty
9	Rear mounting bush, late, each		21A2560	Qty
9	Poly bush kit - late (red or black)		SPDSP664A	Qty
9	Nylon bush kit - late		MSLMS0531	Qty
10	Rear mounting bush - early, each		2A5818	Qty
10	Poly bush kit - early (red or black)		SPDSP662A	Qty
10	Nylon bush kit - early		MSLMS0532	Out of stock
11	Spring washer	each	GFK1125	Qty
12	Long trunnion bolt	each	SH605181	Qty
12	Short trunnion bolt	each	GFK5185	Qty
13	Nyloc nut	each	GFK3323
14	Washer	each	PWZ207	Qty
15	Washer - 5/16"	each	GFK1114	Qty
16	Nut - 5/16" UNF	each	GFK3322	Qty
17	Set Screw - trunnion 5/16" UNF	each	BH605201	Qty
18	Trunnion (rectangle), each		21A2558
19	Trunnion (step), each		2A5819	Qty
